Features:

• Pre-assembled hubs for a clean and simple installation
• 12" galvanized wheels with marine grade sealed bearings
• Reinforced steel tongue can transport boats up to 20' in length
• 78’’ steel, 1 ¼’’ square load bars featuring d-ring tie-downs
• 50" steel, 1 ¼’’ square upper load bars w/ 2nd Tier Kit
• 11 gauge pre-galvanized steel construction for years of service
• Made in the USA
• Five Year Limited Warranty

Specifications:

• Load Capacity: 800 lb / 20' canoe or kayak
• Dimensions: 13' 3" (length)
• Width (Without crossbars): 55"
• Frame Width Assembled (Width within Fenders): 40"
• Weight (Without accessories): 197 lb
• Frame: Marine grade galvanized steel
• Hitch: 2" Class II receiver
• Required Ball Size for Vehicle Attachment: 2"
• Ball Height: 18" From Ground - To Top Of Ball
• Recommended Tire Pressure: 35 to 40 PSI
• Tongue Weight (Unloaded): 25 lb
• Lower Cross Bar Spread (Adjustable): 44" - 63"
• Height of Upper Cross Bars from Ground: 58"
• Height of Lower Cross Bars from Ground: 22"

What’s In The Box:

• (1) MPG474 2nd Tier Kit
• (2) 12" High Speed Wheels
• (1) Reinforced Steel Tongue
• DOT Approved LED Lighting
• Pre-Tested Electrical System
• Pre-Fitted Chassis Components
• (1) Instruction Manual & Registration Documentation
• Total Shipment: 5 Cartons
