EcoLight™ 4 Kayak Trailer Package (1 Stacker & 4 Sets Foam Blocks)

Additional charges for oversized delivery will be applied. Please refer to your cart for more details.

Trailer Accessory Fit Guide

USER MANUAL - ECOLIGHT™ TRAILER
USER MANUAL - STACKER STYLE CARRIERS
5 YEAR LIMITED WARRANTY
PACKAGING DETAILS

The EcoLight™ Sport Trailer, when bundled with a Malone carrier system, provides an excellent choice for safe and affordable kayak transport. We offer a selection of four different trailer/carrier packages to carry one, two or four kayaks.

The MPG586XL EcoLight™ Package is designed to carry four medium sized touring or recreational kayaks. Each trailer comes with one set of stacker style kayak carriers, eight foam kayak blocks and eight load straps. This carrier system works best with traditional V-style hulls.

Each unit is DOT and Transport Canada certified and proudly built in the USA for years of dependable use. Provides safe travel up to a maximum of 65 mph while transporting loads up to 400 lbs. Features a reinforced extra-long tongue, 58" wide steel load bars, molded fenders, 8" high-speed tires and a 2" receiver with lift handle. All parts and workmanship are guaranteed with a Five Year Limited Warranty. Assembles in 3-5 hours with common shop tools. Detailed assembly instructions included.

Features:

  • Marine grade galvanized frame
  • Padded stacker style carriers with mounting hardware and load straps
  • Foam kayak blocks
  • DOT approved submersible LED lighting
  • 8" - five lug high-speed powder coated wheels
  • Injection molded fenders
  • 58" coated steel load bars
  • 2pc extended tongue
  • Flat four wire harness
  • Tongue skid plate
  • Leaf spring suspension
  • Galvanized heavy duty axle
  • Five Year Limited Warranty
  • Made in the USA

Specifications:

  • Width: 58" (55" without cross bars)
  • Frame Width Assembled (Without fenders): 40"
  • Length: 10' 9"
  • Weight: 145 lb. (Without accessories)
  • Capacity: 400 lb. / 14' canoe or kayak
  • Frame: Marine grade galvanized steel
  • Required Ball Size for Vehicle Attachment: 2"
  • Ball Height: 14" From Ground - To Top Of Ball
  • Wheel Specifications: 8" Diameter; Rated to 65 mph
  • Tire Specifications: 4.80 / 4.00-8", Load Range B, (785 LB)
  • Recommended Tire Pressure: 40 PSI, 90 PSI Max
  • Tongue Weight (Unloaded): 12 lb
  • Cross Bar Spread: 38.5" (Fixed)
  • Height of Cross Bars from Ground: 26"

Installation:

  • Please note that the trailer load bar support system has been upgraded and some product imagery does not show the change.
  • Review instructions and check all parts prior to assembly. Register your warranty prior to first time use.
  • Note: The kayak carriers included with this package are designed "for trailer use only". Do not attempt to mount these carriers to any vehicle rooftop.

What’s In The Box:

  • (2) Wheels & Tires
  • (1) Stacker Style Kayak Carriers with Hardware and Load Straps
  • (4) Foam Kayak Block Kits (Sets of 2)
  • (1) 2pc Extended Tongue
  • DOT Approved Lighting & Bearings
  • Pre-Tested Electrical System
  • Pre-Fitted Chassis Components
  • Instruction Manuals & Registration Documentation


Prop 65 WARNING for California residents:
